Kohmann Carton Erecting Machine L1000/2-A

Specifications

Specifications

1. Voltage: 380V/50HZ
2. Covering Area: 4.0M*1.4M
3. The total Power: 8KW
4. Maximum Production Speed: 400 pcs/min
5. AirPressure:0.6Mpa (Dry and clean compressed air)
6. Packing:
   L1000/2-A:
   2960mm*1520mm*1520mm,
   N.W.: 1800KG. G.W.: 2200KG
   1360mm*1360mm*870mm,
   N.W.: 350KG G.W.: 450KG
   L1000/2-B:
   2660mm*1700mm*1560mm,
   N.W. 1800KG. G.W.: 2200KG
   1360mm*1100*1150mm,
   N.W.: 350KG. G.W.: 450KG
7. Materials: Paper Board 200-600gsm; corrugated boarder paper with thickness not exceed 1.5MM

The difference among L1000/2-A/B/C:

L1000/2-A only can make the same box on the two lanes at the same time.
L1000/2-B can make the different ox on the two lanes at the same time.
L1000/2-C adopts machineical device to control the punching head.

Machine type		L1000/2-A
Blank length	L	100mm-450mm
Blank length	B	100mm-420mm
Height of side flaps	H	15mm-220mm
Height of side flaps+lid	H1	50mm-200mm
Height of folded flap	H2	10mm-60mm
Height of folded flap	H3	10mm-50mm
Conicity		5°-40°
